Material Handling Products
Electric Winch
THAC Superior winching technology incorporates a whole series of operating and safety features that will give you a competitive advantage. Winches feature compact dimension and lightweight construction. Electromagnetic spring-applied fail safe brake with a minimum static braking torque of 150% of rated lifting capacity provide instant and safety braking even in the event of power failure. Inside the winch is high efficiency planetary gear trains for TA or TB series winch developing for maximum mechanical efficiency, A tough helical gearing for TC series winch provides the professional solution of all your needs for hoisting, lowering and pulling applications
DOWNLOAD CATALOG
- Compact dimension and lightweight device
- In the event of power loss, an electromagnetic spring-applied fail-safe brake, designed for both static and dynamic load is applied
- Enclosed drum flanges prevent rope from becoming trapped between drum and frames
- Tough and ergonomic steel frames and drum construction
- IP65 pendant switch with an emergency stop button
- 24 VAC control for safety operation
- Inside the winch is the 2 stage planetary gear trains developing for maximum mechanical efficiency
